QDX(QX) Well pumping, river pumping, farming rrigation IPX8 Aluminum Case Sewage Pump Custom

Home / Product / Submersible Sewage Pump / Aluminum Case Sewage Pump / QDX(QX) Well pumping, river pumping, farming rrigation IPX8 Aluminum Case Sewage Pump
QDX(QX) Well pumping, river pumping, farming rrigation IPX8 Aluminum Case Sewage Pump

QDX(QX) Well pumping, river pumping, farming rrigation IPX8 Aluminum Case Sewage Pump

aluminum case sewage pump ,Models QDX(QX) submersible sewage pumps consist of water pump,mechanical seal and single - phase or three-phase asynchronous motor with single-phase for QDX and three -phase for model QX,using centrifugal impeller,small in volume and light in weight

Working Conditions
Max. medium temperature:+40C
Max.ambient temperature:+40C
Max.working pressure:5 bar
Medium free from granules or anything that may
damage the pump.
Power voltage: single-phase AC 220V,
Frequency:50 Hz,
60Hz and three phases AC380V, frequency
50Hz.10 percent more or less voltage fluctuation
from the rated value is allowed.

KEY parts and materials
Pump body: Cast Aluminum or Cast lron
Mechanical Seal: Ceramic -Graphite,ilicon
Stator sheet:DR510 or 470
Motor bracket: Cast Aluminum or Cast Iron
Carbide-Carbide Alloy
Motor shaft: CS 45# or SS420
Impeller: Cast Aluminium

Application
Well pumping, river pumping, farming rrigation,
water supply and drainage in breeding industry
and domestic use, etc.
Brief Introduction
Models QDX(QX) submersible pumps consist of water pump, mechanical seal and single -phase or three-phase
asynchronous motor with single-phase for QDX and three-phase for Model QX, using centrifugal impeller, small in
volume and light in weight.

Feature
Low energy consumption, high eficiency, low noise and stable operation. Close structure with built- -in Thermal
Protector for single- phase motor Protection class:IPX8 Insulation Class: E
Make an inquiry
  • Description1

  • Model



    Voltage

    Freq.

    Power

    Q.rat

    H.rat

    Size

    Dimension

    N.W.

    G.W.

    QTY/20TEU

    V

    Hz

    kW



    m3/h

    m

    (mm)

    (mm)

    (Kg)

    (Kg)

    (pcs)

    QDX1.5-12-0.25

    220

    50

    0.25

    0.34

    1.5

    12

    25

    360X165X165

    5

    5.5

    2850

    QDX1.5-17-0.37

    220

    50

    0.37

    0.5

    1.5

    17

    25

    370X160X195

    6.5

    7

    2400

    QDX1.5-25-0.55

    220

    50

    0.55

    0.75

    1.5

    25

    25

    370X240X220

    9.5

    10

    1500

    QDX3-18-0.55

    220

    50

    0.55

    0.75

    3

    18

    32

    370X240X220

    9.5

    10

    1500

    QDX10-12-0.55

    220

    50

    0.55

    0.75

    10

    12

    38

    370X240X220

    9.5

    10

    1500

    QDX15-7-0.55

    220

    50

    0.55

    0.75

    15

    7

    51

    370X240X220

    9.5

    10

    1500

    QDX1.5-32-0.75

    220

    50

    0.75

    1

    1.5

    32

    25

    395X270X240

    11.5

    12

    1150

    QDX3-24-0.75

    220

    50

    0.75

    1

    3

    24

    32

    395X270X240

    11.5

    12

    1150

    QDX8-18-0.75

    220

    50

    0.75

    1

    8

    18

    38

    395X270X240

    11

    11.5

    1150

    QDX10-16-0.75

    220

    50

    0.75

    1

    10

    16

    51

    395X270X240

    11.5

    12

    1150

    QDX15-10-0.75

    220

    50

    0.75

    1

    15

    10

    64

    395X270X240

    11.5

    12

    1150

    QDX25-6-0.75

    220

    50

    0.75

    1

    25

    6

    76

    400X270X250

    11.5

    12

    1070

    QDX3-30-1.1

    220

    50

    1.1

    1.5

    3

    30

    25

    440X220X205

    13

    13.5

    1460

    QDX15-14-1.1

    220

    50

    1.1

    1.5

    15

    14

    64

    425X280X200

    15.5

    16

    1210

    QDX40-6-1.1

    220

    50

    1.1

    1.5

    40

    6

    76

    450X280X200

    17.5

    18

    1150

    QDX6-25-1.1

    220

    50

    1.1

    1.5

    6

    25

    51

    530X260X270

    24

    28

    775

    QX3-18-0.55

    380

    50

    0.55

    0.75

    3

    18

    32

    370X240X220

    10

    10.5

    1480

    QX1.5-32-0.75

    380

    50

    0.75

    1

    1.5

    32

    25

    395X270X240

    11

    11.5

    1130

    QX8-18-0.75

    380

    50

    0.75

    1

    8

    18

    38

    395X270X240

    11

    11.5

    1130

    QX15-10-0.75

    380

    50

    0.75

    1

    15

    10

    64

    385X195X245

    10

    10.5

    1500

    QX25-6-0.75

    380

    50

    0.75

    1

    25

    6

    76

    400X270X250

    10.5

    11

    1700

    QX3-30-1.1

    380

    50

    1.1

    1.5

    3

    30

    25

    440X220X205

    11.5

    12

    1460

    QX6-25-1.1

    380

    50

    1.1

    1.5

    6

    25

    51

    530X260X270

    24

    28

    740

    QX15-14-1.1

    380

    50

    1.1

    1.5

    15

    14

    64

    425X280X200

    14.5

    15

    1210

    QX40-6-1.1

    380

    50

    1.1

    1.5

    40

    6

    76

    450X280X200

    16.5

    17

    1150

    QX25-12-1.5

    380

    50

    1.5

    2

    25

    12

    64

    425X280X200

    16.5

    17

    1210

    QX40-9-1.5

    380

    50

    1.5

    2

    40

    9

    76

    450X280X200

    17.5

    18

    1150

    QX10-34-2.2

    380

    50

    2.2

    3

    10

    34

    51

    530X280X300

    37

    42

    500

    QDX1.5-17-0.37(T)

    220

    50

    0.37

    0.5

    1.5

    17

    25

    370X160X195

    11

    11.5

    2400

    QDX1.5-25-0.55(T)

    220

    50

    0.55

    0.75

    1.5

    25

    25

    370X195X195

    15

    15.5

    1990

    QDX3-18-0.55(T)

    220

    50

    0.55

    0.75

    3

    18

    32

    370X195X195

    14.5

    15

    1990

    QDX10-12-0.55(T)

    220

    50

    0.55

    0.75

    10

    12

    38

    370X195X195

    15

    15.5

    1990

    QDX15-7-0.55(T)

    220

    50

    0.55

    0.75

    15

    7

    51

    370X195X230

    15

    15.5

    1680

    QDX1.5-32-0.75(T)

    220

    50

    0.75

    1

    1.5

    32

    25

    380X220X220

    17

    17.5

    1500

    QDX3-24-0.75(T)

    220

    50

    0.75

    1

    3

    24

    32

    395X195X195

    16

    16.5

    1800

    QDX8-18-0.75(T)

    220

    50

    0.75

    1

    8

    18

    38

    395X195X220

    16.5

    17

    1600

    QDX10-16-0.75(T)

    220

    50

    0.75

    1

    10

    16

    51

    395X195X220

    16.5

    17

    1600

    QDX15-10-0.75(T)

    220

    50

    0.75

    1

    15

    10

    64

    395X195X240

    16.5

    17

    1500

    QX8-18-0.75(T)

    380

    50

    0.75

    1

    8

    18

    38

    395X195X220

    16.5

    17

    1600

    QX10-16-0.75(T)

    380

    50

    0.75

    1

    10

    16

    51

    395X195X220

    16.5

    17

    1600

    QX15-10-0.75(T)

    380

    50

    0.75

    1

    15

    10

    64

    395X195X240

    16.5

    17

    1500



    The QDX(QX) submersible sewage pump consists of water pump, mechanical seal and single-phase or three-phase asynchronous motor with single-phase for QDX and three-phase for Model QX, using centrifugal impeller. Close structure with built-in Thermal Protector and high efficiency, low noise and stable operation.
    QDX(QX) submersible sewage pumps consist of water pump, mechanical seal and single-phase or three-phase asynchronous motor with single-phase for QDX and three-phase for Model QX. Using centrifugal impeller, small in volume and light in weight. low energy consumption, high eficiency and stable operation.
    This QDX(QX) submersible sewage pump is made of high quality aluminum alloy casting, anticorrosive and forever service life. It's suitable for sanitary environment with medium or light corrosivity, such as for sewerage, drainage and other pumping s
    QDX(QX) submersible sewage pumps are specially designed to meet the requirements of modern sewage pumping equipment.The structure is close with built-in thermal protector for single- phase motor protection class:IPX8 insulation class E or F
    We can produce aluminum submersible sewage pump , Q series, it is a special filter pump for water purification system, an ideal choice for the project like well pumping, river pumping and so on.
    Our pumps are made of aluminum case, so they are more lightweight and durable. The pumps itself is resistant to rainwater, and it can also resist most chemicals.The impeller is fluted, which improves its eficiency.
